| Cutting Diameter (DC) | 10 mm | Flute Helix Angle (FHA) | CW |
| Connection Diameter Machine Side (DCONMS) | 10 mm | Shank Type | Round |
| Depth of Cut Maximum (APMX) | 13 mm | End Shape | Chamfer |
| Overall Length (OAL) | 50 mm | Usable Length (LU) | 13 mm |
| Cutting Edge Material | Carbide | Corner Chamfer Width (CHW) | 0.5 mm |
| Coating | AlTiN | Grade | KC643M |
| Flute Count (NOF) | 4 | Decimal Equivalent | 0.3937″ |
Product Features
| Remarks | •Single tool for both roughing and finishing operations for fewer setups. •Unequal flute spacing minimizes chatter for smoother machining.Kennametal standard dimensions.Centre cutting. | Country of Origin | USA |
Shipping Info
Package Weight
.1257
